ASTERA AX1 PIXELTUBE 28W LED

  • $450.00
    Unit price per
  • Save $135
Shipping calculated at checkout.


AX1 PIXELTUBE

 PLSN Gold Star Product Award

28W RGBW LEDs – 180° Beam Angle

AX1 is a powerful pixel controllable LED RGBW baton that can be mounted at event and film sites to light up people and objects or create indirect lighting effects. A highly creative device that offers an infinite range of possibilities.

AX 1 Wireless Pixel Tube built-in rechargeable Samsung battery; RF, IR controlled, and via CRMX Wireless DMX; 28W power; 16 pixel segments; IP65; Incl, stand, 2 x eye-bolts, 2 x holder (Includes charger)


Optical

Colours: RGBW

Total LED power: 28W

Lumens: 955Lm

CRI: up to 88

Strobe:  0-25Hz

Beam Angle: 180˚

Pixels: 16

Electrical

Battery: LG Chem Lithium-ion

Battery Lifetime: 70% after 300 cycles

Battery Runtime: Up to 20 hours

LED Lifetime: 50.000 Hours

Charging time (nominal): 7 Hours

Input Voltage (charger): 90-264V 47-63Hz

Input Voltage (Light): 48V 0.5A

Control

Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz

Range: 300m | 330 Yards

Wired DMX: not supported

Wireless DMX: CRMX & others, excluding W-DMX G5, City Theatrical



Construction

Housing: Polycarbonate, metal endcap

IP Rating: IP65

Relative humidity: 0-100%

Operating Temperature: 0-40 ˚C | 32-104 ˚F

Weight: 1kg |2.2Lbs

Dimensions: Ø42 x 1035mm | Ø1.6” x H40.7”
